MSI B650M GAMING Plus WIFI AMD AM5 mATX Motherboard

MSI B650M GAMING Plus WIFI AMD AM5 mATX Motherboard

Key Feature

Supports AMD Ryzen 8000/ 7000
Chipset AMD B650
Memory Support DDR5
Realtek RTL8125BG 2.5Gbps LAN

Stock: In Stock
Brand: MSI
Model: B650M GAMING PLUS WIFI

Based on 0 reviews. - Write a review

20,700৳

Ex Tax: 20,700৳

Qty

Add to Cart

Buy Now Buy Now

Add to Wish List Compare this Product

***It is requested to know about the stock and delivery of the product before ordering।*

Key Features
Form Factor	mATX
Connectivity
HDMI	1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz*
Basic Information
Supported CPU	Supports AMD Ryzen 8000/ 7000 Series Desktop Processors
Memory	Memory Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO™ Max. overclocking frequency: • 1DPC 1R Max speed up to 7200+ MHz • 1DPC 2R Max speed up to 6000+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5400+ MHz
Memory
Slots	1x PCI-E x16 slot • Supports x16 (For Ryzen™ 7000 Series processors) • Supports x8 (For Ryzen™ 7 8700G and Ryzen™ 5 8600G processors) • Supports x4 (For Ryzen™ 5 8500G processor) 2x PCI-E x1 slot PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E2 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
Network & Connectivity
Lan	Realtek RTL8125BG 2.5Gbps LAN
WiFi	AMD Wi-Fi 6E
Bluetooth	AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.3**
General information
DIMENSION	243.84mmx243.84mm
Graphics	1x HDMI™ Support HDMI 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz*
Chipset
Chipset Model	AMD B650
Connector & Ports
External I/O Ports	DisplayPort 2.5G LAN USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 1 5Gbps (Type-A) Wi-Fi / Bluetooth Flash BIOS Button HDMI™ USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-C) Audio connectors
Internal I/O Ports	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports
Physical Specification
USB	4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 3x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Rear) 1x USB 10Gbps Type C (Front)
Warranty Information
Warranty	3 Years

MSI B650M GAMING PLUS WIFI AM5 mATX Motherboard – The Perfect Choice for Next-Gen Gaming & Performance

The MSI B650M GAMING PLUS WIFI AM5 Micro-ATX Motherboard is designed for gamers and PC enthusiasts who need a compact yet powerful platform for their builds. Supporting the AMD Ryzen 8000 & 7000 Series Desktop Processors, this motherboard ensures top-tier performance for gaming, content creation, and multitasking.

Durable mATX Form Factor & Warranty

With a Micro-ATX (mATX) form factor (243.84mm x 243.84mm), this motherboard is perfect for compact gaming builds without compromising on features. Backed by a 3-year warranty, it offers reliability and peace of mind.
